Precise Numerical Control Plane Grinding Machine
Author:Memg Dan
Tutor:Deng Zhaohui
Abstract
This paper makes a thorough exposition of the designed grinding machine from the aspects of its overall design,horizontal and portrait give and hardware circuit design.The following is a brief introduction of the composition of this paper.
INTRODUCTION: It introduces the background of this subject research ,the development in this field internal and international, and the assignment of this graduation project.
THE OVERALL DESIGN OF THE NUMERICAL CONTROL PLANE GRINDING MACHINE: It gives a brief introduction to the design of the numerical control plane grinding machine, and provides its technical specification , main structure and explanation of the numerical control plane grinding machine , and show the design of the overall transmission of the grinding machine and the design of the overall arrangement.
THE THEORETIC CALCULATION: It introduces the calculation of the power of lathe , the selection of the motor, the selection and check of the ball pole and the theoretic calculation of the size of the cone gear wheel.
CONCEPTUAL DESIGN: It introduces the main points and requirements of the design of the drive parts, and puts forward the design of the horizontal and portrait give parts.
THE DESIGN OF HARDWARE CIRCUIT: The election of the hardware and the connection of circuit are explained at length.
In view of the flaws of the design, it puts forward some measures to make impovement. Besides, a conclusion of this graduation project and prospect of the development of precise machine are given in this part.
Keyword: plane grinding machine , numerical control, portrait give, horizontal give
...
